Audio Products
EZ-MON HD
The high resolution 5" LCD panel gives a bright clear image, whilst the amply powered stereo loudspeakers enable effortless monitoring. Headphone
output too for privacy or noisy environments. A unique feature of the compact 2U, self-contained Murraypro EZ-MON HD, is the choice of 3 different audio
metering strategies; select between the Audio Histogram, PPM or VU options.
Ki-Pro Monitoring Unit
Murraypro's completely self-contained Ki-Pro Monitoring Unit sports a Hi-Res LCD panel and powerful 8W wide response loudspeaker, providing immediate
monitoring of the Ki-Pro’s Recording and Playback functions via the Composite OP and unbalanced Phono OPs. A strategy that frees up all the SDI, HDMI,
Component Video and XLR Audio connectors for use in your installation....there is no hogging of vital signal ports by our Monitor. The Ki-Pro stereo OP is
fed via independent L & R channel muting to the loudspeaker’s monaural mixer, a useful monitoring feature which helps guard against Operational audio
'Phase' errors. The Unit even provides regulated 12V power, on an XLR4, for your Ki-Pro.
Compact-Duo HD PPM
Touch-latch switching between the 4 embedded Groups provides Flyaway Kit, Edit Suites and CARs with cost effective Audio Monitoring on generously
sized "Type 29" PPM, either free standing or 2U rack’d. Fully buffered Volume OPs allow for HP or high quality monitoring on external Speakers in larger
Control Rooms. Front panel switching facilitates instant selection between Channel 1 & 2 or Channel 3 & 4 of the selected Group. A balanced fully
buffered 4 Ch utility OP of the selected Group is provided on rear panel XLRs. PHASE monitoring and Peak LEDs.
PICO Program Meter
The PICO has carved a niche for itself in "audio-for-editing" equipment, and this Industry ‘stalwart’ is frequently specified in High End installations
throughout the Industry. PPM monitoring is provided on 2 illuminated miniature meters. True PPM scaling (4dB/division) together with the classic fast attack
(with minimal overshoot!) and slow decay times are ensured by the full specification precision meter drive amplifier. The miniature movements that are fitted
in this 1 U height have a very slightly relaxed specification, but closely emulate the full-sized BS 6840 meters, and boast a surprisingly large 42 x 20 mm
scale. PHASE monitoring and Peak LEDs.
Mini-Mon3 PPM
Versatile and compact audio monitoring in 1U provides IP switching between 4 Stereo Groups, Speakers, Phones, PPM, PHASE & Peak LED. Busy Facility
Houses are often switching between material recorded with Reference levels of -18dBFS (EBU) or -20dBFS (SMPTE). This switched 2dB gain
normalisation feature is a most welcome feature; allowing conventional PPM monitoring of of both ‘EBU’ & ‘SMPTE’ Programme Material, with reference
levels instantly normalised to “PPM 4”, whilst the absolute programme level remains totally unchanged at all times.
PPM-8
To accomodate the proliferation of multi-channel audio programme production, Murraypro has designed PPM 8, offering 8 Channels of PPM in only 1U,
ideal for "5.1" & "6.1". PEAK level indication is provided for each audio channel and PHASE monitoring is provided on Go/NoGo green-red LED between
pairs of inputs, maximising the PPM-8's usefulness in applications where stereo pairing is required.
Compact LCD Audio Monitoring Unit
Compact LCD the answer to your requirement for flexible HD/SD Monitoring in a compact unit, ideal for Flyaway Kit, Edit Suites and CARs, which may be
used either free-standing or racked in a 1/2 width 3U "WFM" chassis frame to provide comprehensive and cost effective monitoring facilities. A major
feature of the Compact-LCD is the 16 Channel Histogram, which can also be switched to TV IP, or TV + 4 Ch histogram ‘burnt in’. Menu options allow
selection of the Histogram's Graticule scaling to cover PPM, Nordic, Digital or VU requirements.
Compact Quad Audio Monitoring Unit
4Ch Embedded & Bal Analogue PPM Metering + Stereo loudspeakers. Compact QUAD is the answer to your requirement for flexible HD/SD and Balanced
audio Monitoring in a compact unit. PHASE monitoring and Peak LEDs. Ideal for Flyaway Kit, Edit Suites and CARs, which may be used either free-
standing or racked in a 1/2 width 3U "WFM" chassis frame to provide comprehensive and cost effective monitoring facilities.
AES & SPDIF demodulators
The Cat: 390A/S demodulator has been designed to be fitted within analogue audio equipment that lacks a dedicated AES/EBU digital input, and provides a
transparent interface with the external digital input. Two AES channels are housed on the compact card only 80 x 50 mm, each furnishing a balanced audio
OP, ie 4 Ch OP The modest power requirements of the card are drawn from the host equipment, removing the requirement for a separate external power
supply.
SPDIF+TOS to AES Conversion
This handy little unit has been developed to interface between Equipment that offers either an SPDIF 75 ohm OP, or a TOS optical OP. Elegantly the Unit
automatically changes over between SPDIF or TOS operation; the only proviso being that no attempt is made to use both inputs simultaneously! The Unit
does NOT modify the protocol of the data stream so, "what goes in, comes out". It does however provide an interface that accurately matches SPDIF and
TOS inputs at 44/48 & 96KHz Word Clock, providing both level and impedance conversion, ensuring that Equipment with AES 3 protocol input is correctly
driven. Locking low voltage connector from external PSU with universal mains IP on IEC320.
Compact-Duo Analogue PPM
Touch-latch switching between 4 stereo Groups provides Flyaway Kit, Edit Suites and CARs with cost effective analogue Audio Monitoring on generously
sized "Type 29" PPM, either free standing or 2U rack’d. Fully buffered Volume OPs allow for HP or high quality monitoring on external Speakers in larger
Control Rooms. Front panel switching facilitates instant selection between Channel 1 & 2 or Channel 3 & 4 of the selected Group. PHASE monitoring
and Peak LEDs.
